See examples :

Click on numbers
below

Example support :

A wind turbine model must react to the wind speed by correcting the inclination of the blades when the wind gets too strong. For this the orientation of the blades is linked to the spacing of weights subjected to the centrifugal effect balanced by an elastic.

The product has 7 sub-assemblies and a global assembly to build :




Objective : Understand a method of creating assemblies
